K - SO63, K - SO175, K - S200 Shielded Lead - Out Solder Rings

Application

Shielded solder rings are applicable for shielded grounding terminal treatment.

Characteristics

-Integrated structural design

-The transparent heat - shrinkable tube ensures the continuity of the insulating layer and provides stress relief.

-The precisely formulated solder and flux ensure clean solder joints and reliable soldering, reducing the soldering skill requirements for workers.

-The melting of thermoplastic material ensures the sealing at both ends of the solder joint.

-Optional pre - installed leads can be used to extract shielded signals.

Operating Temperature

-The continuous operating temperature of the K - SO63 series: - 55°C to 150°C

-The continuous operating temperature of the K - SO175 series: - 55°C to 175°C

-The continuous operating temperature of the K - S200 series: - 55°C to 200°C
